MiTR School Bus Specification

Engine

  • Max Power103 kW (140hp) @ 2750 rpm
  • Max Torque360 Nm @ 1350-2750 rpm
  • EngineZD 30 DDTi Common Rail Diesel Engine
  • Wheelbase3700 mm
  • Fuel TypeDiesel

Variant

  • 2×2 (Wide Body) AC and NON AC22+A+D (HB, SD)
  • 2×2 (Wide Body) AC and NON AC26+A+D (STD, SD)
  • 2×2 (Wide Body) AC and NON AC24+A+D (STD, DD)
  • 3×3 (Wide Body) AC and NON AC39+A+D(STD,SD)
  • 3×3 (Wide Body) AC and NON AC36+A+D(STD,DD)
  • 3×2 (Wide Body) NON AC33+A+D(STD,SD)
  • 3×2 (Wide Body) NON AC31+A+D(STD,DD)

Dimension

  • Wheelbase3700 mm
  • Overall length7060 mm
  • Overall Width2200 mm
  • Overall Height2630 mm
  • Overall Dimension Wide Body (L×W×H) (mm)(7060×2200×2630) mm (Non-AC), (7060x2200x2850) mm (AC)
  • Min. Turning Radius 7.2 m
  • Min. Ground Clearance 198 mm

Suspension

  • Front Parabolic Suspension with Double Acting Shock Absorbers
  • Rear Parabolic Suspension with Double Acting Shock Absorbers

Steering

  • TypePower Steering

Clutch

  • Type310 mm Diameter
